OBD 2 OBD2 16pin Male Female Pass Through to OBDII 16 Pin Main Cable

OBD 2 OBD2 16pin Male Female Pass Through to OBDII 16 Pin Main Cable


Specification


We opened plastic molds of the OBD2 OBDII OBD connectors and plugs. 24AWG or 26AWG pure copper quality wires are employed to manufacture these cables. We can always make the cables with excellent connectivity and durability.

The connecting part of the OBD2 male and female pass-through can be overmolded or assembled. If it is assembled, there are 2 pcs of small top and bottom plastic enclosures and these 2 pcs of plastic enclosures are assembled together after the wires are soldered to the pins.


The overmolded PVC injection at the end of 16-Pin OBD2 OBDII female connector is right angle 90-degree. The overmold is with slim design. These features can help save some space when connecting and installing telematics devices.


Pin assignment or pin out

The pin assignment or pin out can be like this:


As to this pin out, Pin 4 and Pin 5 of the OBD2 OBDII male and female connectors are connected together with a short wire. The black wire in the main cable is connected to Pin 4 or Pin 5. There are 9 pins wired, but there are 8 wires of 26AWG in the main cable.

The pin assignment or pin out can also be like this:


As to this pin out, all 16 pins of the OBD2 male and female connectors are wired, so there are 16 wires of 26AWG in the main cable.

The pin assignment or pin out can also be customized according to your needs. If there is no need for more pins to be connected, we suggest we just connect the necessary pins you need and the price can be lower because the raw material and labor cost is lower.


Application

This OBD2 male and female pass-through to female extension cable is used to connect telematics, IoV devices, fleet management devices, OBD2 GPS trackers, OBD2 CAN programming tools, ECU tuning tools or car performance tuning tools to vehicles' 16-Pin OBD2 female diagnostic ports.

This cable allows port relocation or connection of multiple devices. Multiple devices can be connected to the OBD2 female diagnostic port with this cable. This cable splits the original OBD2 female diagnostic port.

This cable can also connect OBD2 diagnostic devices or scanners or fault code readers (with the appropriate software) to OBD2 female ports in cars, mainly for dignostic purposes.


Sending an inquiry


If you haven’t found or don’t have time to look for the OBD2, 9-Pin J1939 or 6-Pin J1708 cables, adapters or connectors in our website, feel free to let us know what OBD2, 9-Pin J1939 or 6-Pin J1708 cables, adapters or connectors you need by sending an inquiry (If you have a picture, please attach it in the inquiry). We can also customize any OBD2, 9-Pin J1939 or 6-Pin J1708 cables, adapters or connectors for you.

Skype: orchard.guo (any time to contact)
